Faster-Charging, Safer Batteries

Estimated reading time: 6 minutes

Imagine a world where cell phones and laptops can be charged in a matter of minutes instead of hours, rolled up and stored in your pocket, or dropped without sustaining any damage. It is possible, according to University of Delaware Professor Thomas H. Epps, III, but the materials are not there yet.

So, What is Holding Back the Technology?

For starters, it would take more conductive, flexible and lighter-weight batteries, said Epps, who is the Thomas and Kipp Gutshall Professor of Chemical and Biomolecular Engineering and a professor in the Department of Materials Science and Engineering at UD.

The batteries would need to be more impact-resistant and safer, too. In May, an e-cigarette exploded in Florida and killed a man. Evidence reportedly suggests that this unfortunate accident may be due to battery-related issues, according to the U.S. Food and Drug Administration. Similar problems have plagued devices like the Samsung Galaxy Note 7 and auxiliary power units of the Boeing Dreamliner.

“All of these challenges came from batteries that have safety and stability issues when the goal is to push performance,” said Epps, an expert in designing and fabricating conducting membranes useful in energy generation and storage devices.

One way to overcome this challenge in the lithium-ion batteries for the above devices is to improve the battery membranes — and the associated electrolytes — that are designed to shuttle the lithium ions, which offset the electrical charge associated with charging and discharging the battery.

At UD, Epps’ team has patented an idea to improve battery performance by introducing tapers into the polymer membrane electrolytes that allow the lithium ions inside the battery to travel back and forth faster.

It is a big idea that begins with tiny parts.

Small Science, Big Impact

It all starts with polymers, which are materials made of small molecules strung together like beads on a necklace to create a long chain. By chemically connecting two or more polymer chains with different properties, engineers can create block polymers that capitalize on the salient features from both materials. For example, polystyrene in a Styrofoam cup is relatively hard and brittle, while polyisoprene (tapped from a rubber tree) is viscous and molasses-like. When those two polymers are linked chemically, engineers can create materials for everyday items like car tires and rubber bands — materials that hold their shape but are impact resistant and stretchable.

Epps was introduced to block polymers as an undergraduate student at the Massachusetts Institute of Technology while working in the lab of Professor Paula Hammond, and again when he worked at the Goodyear Tire & Rubber Company under Adel Halasa as part of a GEM Fellowship. Goodyear was exploring the use of taper-like multi-component polymers to create tires with more elasticity, tires that would grip the road better without sacrificing performance or durability.

Years later, in work at UD, Epps’ group took the idea a step further and realized they could tune the nanoscale (1/1,000th the width of a human hair) structure of these polymers to imbue materials with certain mechanical, thermal and conductivity properties.

One of the benefits of block polymers is that they allow scientists to combine two or more components that often are chemically incompatible, meaning they do not mix (think of oil and water). This same benefit, however, can present challenges with how the materials can be processed. The Epps group determined that tapering the region where the two distinct polymer chains connect can promote mixing between highly incompatible materials in a way that makes processing and fabrication faster and cheaper by requiring either less energy or less solvent in the manufacturing process.

Manipulating the taper also allowed the researchers to control the nanoscale structures that can be formed by the block polymers. By incorporating the tapers, Epps’ team can create nanoscale networks that make the battery materials more conductive—introducing nanoscale highways and eliminating traffic bottlenecks, allowing ions to move at higher speeds and making the polymer more efficient in battery applications.

 “Technically, we want to conduct ions faster … this approach in polymers would allow us to get more power out of the batteries. It would enable the batteries to charge faster, in a manner that is also safer. We are not there yet, but that is the goal,” said Epps, who patented the concept through UD’s Office of Economic Innovation and Partnerships.

He calls this work a “designer approach” to polymer science.
