Essemtec Announces Placement & Jetting in a Single Pass Through with the New FOX2
January 10, 2017 | EssemtecEstimated reading time: 1 minute
Essemtec today announced plans to exhibit in Booth #1223 at the 2017 IPC APEX EXPO, scheduled to take place Feb. 14-16, 2017 at the San Diego Convention Center in California. Essemtec will debut the FOX² and demonstrate the compact Spider jet dispenser.
The new FOX2 by Essemtec combines jetting of solder paste or glue and placement in a single machine. The new version is based on the original award-winning platform, which is the first machine in its class with linear motors and a mineral cast frame, providing excellent speed, stability, accuracy, and making it perfectly suited for use in small to medium production environments. FOX2 has a machine footprint of just 1m2 and can accept PCB sizes up to 16 x 12". Components with sizes from 01005 up to 1.3 x 3.1"are placed. The machine achieves 7,500 cph (IPC9805A) at 50 µm, 3 sigma with a two nozzle head.
The Spider can utilize two dispensing Jet valves rated at up to 150,000 dots per hour. It dispenses 3D patterns and is easily adapted to your application. The Spider occupies only 1 m² of floor space and features linear motor drives for high accuracy: 40 µm (3σ) at full speed. Job changeover is quick with intuitive CAD import and job preparation. Mapping of heights by laser technology enables 3D applications. A mineral-cast chassis provides stability at varying temperatures.
About Essemtec AG
Essemtec AG is a privately held Swiss equipment manufacturer, specializing in high speed fluid dispensing as well as flexible high-mix SMT placement solutions. Both divisions leverage the company’s vast equipment and process know-how gained since 1991 to let their customers achieve significant competitive advantages. The company’s goal is to improve its customers’ workflows, setup times, defect rates, traceability and overall manufacturing efficiency through superior software and by providing managed SMT storage.
