CyberOptics to Demo 3D AOI Platform at SMT Nuremberg
May 8, 2018 | CyberOptics CorporationEstimated reading time: 1 minute
CyberOptics Corporation will demonstrate the MRS-Enabled SQ3000 with multi-process capabilities including 3D AOI, SPI and CMM applications at SMT Nuremberg, Germany, June 5-7 at the Messe GmbH in hall 4, stand 101.
The SQ3000 offers a combination of unmatched accuracy and speed with the industry-leading Multi-Reflection Suppression (MRS) sensor technology that meticulously identifies and rejects reflections caused by shiny components and surfaces. Effective suppression of multiple reflections is critical for highly accurate measurement, making the proprietary MRS technology an ideal solution for a wide range of applications with exacting requirements.
The SQ3000, deemed best in class, has been widely used for 3D Automated Optical Inspection (AOI) and can now be used for 3D Solder Paste Inspection (SPI) for the best accuracy, repeatability and reproducibility – even on the smallest paste deposits. Combined with the award winning, easy-to-use SPI software, solder paste inspection has reached a new level of precision for the most stringent requirements.
Additionally, the SQ3000 can be used to attain highly accurate coordinate measurements faster than a traditional Coordinate Measurement Machine (CMM) – seconds, not hours. The world’s first in-line CMM includes a comprehensive software suite for use in industrial metrology, semiconductor, microelectronics and SMT applications.
Customers worldwide are using the SQ3000 3D Inspection and Measurement system to improve yields, quality and operational efficiencies in their manufacturing facilities.
About CyberOptics
CyberOptics Corporation is a leading global developer and manufacturer of high precision sensing technology solutions. CyberOptics sensors are being used in general purpose metrology and 3D scanning, surface mount technology (SMT) and semiconductor markets to significantly improve yields and productivity. By leveraging its leading edge technologies, the company has strategically established itself as a global leader in high precision 3D sensors, allowing CyberOptics to further increase its penetration of its key vertical markets. Headquartered in Minneapolis, Minnesota, CyberOptics conducts worldwide operations through its facilities in North America, Asia and Europe.
For more information, click here.
