MIRTEC to Exhibit 3D AOI and SPI Systems at IPC APEX EXPO 2017

Estimated reading time: 4 minutes

MIRTEC will premier its complete line of 3D AOI and SPI Systems in Booth 3101 at the 2017 IPC APEX EXPO. The premier technical conference and exhibition for the electronics manufacturing industry will take place February 14-16, 2017 at the San Diego Convention Center.

"We are very excited about the products that we will be presenting at APEX 2017," stated Brian D'Amico, President of MIRTEC’s North American Sales and Service Division. "MIRTEC will feature a total of seven inspection systems specifically designed to address the full spectrum of inspection requirements associated with the electronics manufacturing industry."

The award-winning MV-6 OMNI 3D AOI Machine is configured with MIRTEC’s exclusive OMNI-VISION® 3D Inspection Technology which combines our 15 Mega Pixel CoaXPress Camera Technology with MIRTEC’s revolutionary Digital Multi-Frequency Quad Moiré 3D system in a newly designed cost effective platform.  MIRTEC’s 15 Mega Pixel CoaXPress Vision System is a proprietary camera system designed and manufactured by MIRTEC for use with our complete product range of 3D inspection systems. MIRTEC’s Digital Multi-Frequency Quad Moiré Technology, provides true 3D inspection using a total of four (4) Programmable Digital Moiré Projectors to yield precise height measurement data used to detect lifted component and lifted lead defects as well as solder volume post reflow.  Fully configured the new MIRTEC MV-6 OMNI machines feature four (4) 10 Mega Pixel Side-View Cameras in addition to the 15 Mega Pixel Top-Down Camera. There is little doubt that this new technology has set the standard by which all other inspection equipment is measured.  MIRTEC will have two (2) MV-6 OMNI’s on display one configured with a 10um lens for High-Performance applications and the other with a 15um lens for High-Speed applications.

MIRTEC’s award-winning MS-11E 3D SPI Machine is configured with MIRTEC’s exclusive 15MP CoaXPress Vision System, providing enhanced image quality, superior accuracy and incredibly fast inspection rates.

The machine uses Dual Projection Shadow Free Moiré Phase Shift Imaging Technology to inspect solder paste depositions on PCBs post screen print for insufficient solder, excessive solder, shape deformity, shift of deposition and bridging.  The MS-11e uses the same robust platform as MIRTEC’s MV-6 OMNI Series.

MIRTEC will have two (2) MS-11e’s on display one configured with a 10um lens for High-Performance applications and the other with a 15um lens for High-Speed applications.

MIRTEC’s MV-7 OMNI-QHD 3D AOI Machine features the next generation of MIRTEC’s award-winning OMNI-VISION® 3D Inspection Technology in a High-Performance AC Servo Drive Platform.  This revolutionary technology combines our proprietary 15MP CoaXPress Vision System with MIRTEC’s exclusive Quantum High Definition (2048x1536) Digital Multi-Frequency 3D Projection Technology to provide unprecedented image quality, accuracy and repeatability necessary for precision inspection of SMT devices on finished PCB assemblies. This new technology will, undoubtedly, set the standard by which all other 3D inspection equipment will be measured. The MV-7 OMNI-QHD machine also features four (4) 10 Mega Pixel Side-View Cameras for inspection of Regions of Interest which are not accessible with the 15 MP Top-Down Camera.

MIRTEC’s MV-6E In-Line AOI Machine combines our exclusive 10 Mega Pixel Top-Down camera with a Precision 13.4um Telecentric Compound Lens and four (4) 10 Mega Pixel Side-View Cameras in a newly designed cost effective platform. The MV-6e is also configured with MIRTEC’s exclusive INTELLI-SCAN® 3D Laser System, providing superior lifted lead detection for gull wing devices and four-point height measurement capability for co-planarity testing of BGA and CSP devices.

The MV-3L Desktop AOI Machine is the industry’s most widely accepted five (5) camera desktop AOI system.  This system is configured with one Top-Down View 10 Mega Pixel camera with a Precision 13.4um Telecentric Compound Lens and four (4) 10 Mega Pixel Side-View Cameras.  It also features our exclusive INTELLI-BEAM® 3D Laser System. This advanced technology provides: four-point height measurement capability for co-planarity testing of BGA and CSP devices as well as enhanced solder paste measurement capability.

New at the IPC APEX EXPO, MIRTEC will feature an MV-3L OMNI 3D Desktop AOI Machine.  The MV-3L OMNI is configured with MIRTEC’s exclusive OMNI-VISION® 3D Inspection Technology which combines our 15 Mega Pixel CoaXPress Camera Technology with MIRTEC’s revolutionary Digital Multi-Frequency Quad Moiré 3D system in a newly designed desktop platform.  MIRTEC’s 15 Mega Pixel CoaXPress Vision System is a proprietary camera system designed and manufactured by MIRTEC for use with our complete product range of 3D inspection systems.  MIRTEC’s Digital Multi-Frequency Quad Moiré Technology, provides true 3D inspection using a total of four (4) Programmable Digital Moiré Projectors to yield precise height measurement data used to detect lifted component and lifted lead defects as well as solder volume post reflow.  Fully configured the new MIRTEC MV-3L OMNI machine features four (4) 10 Mega Pixel Side-View Cameras in addition to the 15 Mega Pixel Top-Down Camera.

MIRTEC’s total quality management system software, INTELLISYS® also will be on display at the IPC APEX EXPO. This software suite promotes continuous process improvement by allowing manufacturers to track and eliminate defects on inspected assemblies.

“MIRTEC has earned a solid reputation in the industry by providing unprecedented performance, quality and cost-effectiveness to the inspection environment,” continued D’Amico, “We look forward to welcoming visitors to our booth #3101 during the three-day event.”

About MIRTEC

MIRTEC is a leading global supplier of automated inspection systems to the electronics manufacturing industry.  For further information, please click here.
