Koh Young Adds Value to Pre-Reflow with Panasonic APC System

Estimated reading time: 1 minute

Koh Young Technology announces its Zenith 3D AOI System is fully connected to Panasonic NPM and APC (Advanced Process Control) Systems. The Zenith 3D AOI System is the first certified APC-ready 3D AOI for 0201M components, which can improve yields in high density placements. The Koh Young Zenith 3D AOI can feed correct mounting position values to Panasonic NPM mounters ensuring components are mounted in the targeted position as intended. This feature, also known as APC-MFB (Advanced Process Control-Mounter Feedback), improves process repeatability by automatically adjusting component placement to the paste, rather than to the pad location. Moreover, APC-MFB will catch the shift trend and conduct further position correction by using true 3D measurement data from the Zenith AOI system.

To achieve this M2M feedback, Koh Young has undergone rigorous verification with 10um and 15um Zenith 3D AOI systems. Upon successful completion of testing, Koh Young has been certified for 0201M components in addition to 0402M components; making them a leading solution provider for microchip mounting reliability.

Commenting on their successful partnership with Panasonic Smart Factory Solutions Co. Ltd, Nobuo Kobayashi, Managing Director of Japan Koh Young Co. Ltd, commented, "We are honored to join the trusted APC Alliance as our vision is to deliver Agile Manufacturing innovation to our customers. We believe our superior feedback capability of the APC ready Zenith will deliver quality pre-reflow yield and develop minimum industry standards for narrow pitch placement of microcomponents."

In addition to this innovation, Koh Young will highlight a broad range of additional technologies, while taking part in several show activities, including topical roundtable discussions and interviews on the smart factory and inspection process. Visit Koh Young at booth 2733.

About Koh Young Technology Inc.

Koh Young Technology Inc., the leading 3D measurement-based inspection equipment and solutions provider, performs an essential role for quality control and process optimization across a growing set of industries including printed circuit board assembly, machining and assembly process manufacturing, semiconductor manufacturing, and various medical fields. In addition to its corporate headquarters in Seoul, Koh Young has sales and support offices in Germany, Japan, Singapore, China, and the United States. The local facilities ensure Koh Young provides close communication and support to its customers, while providing a global network of process experts.
