MIRTEC Europe Wins Best of Industry Award
November 11, 2019 | Mirtec EuropeEstimated reading time: 1 minute
MIRTEC, “The Global Leader in Inspection Technology,” has won an EM Best of Industry Award in the category of Automated Optical Inspection for its MV-6e OMNI. The award was presented to Bentec distributor Accurex Solutions during a ceremony on 26 September at the Stellar Gymkhana in India. Bentec is MIRTEC’s managing partner for UK/Ireland and India.
“We are honored to have won a 2019 Best of Industry award from Electronics Maker,” said David Bennett, managing director of Bentec Ltd. “Earning more than 40 industry awards for our technologically advanced inspection solutions lets us know that we are on the right path to providing our customers with the best quality products and services available today.”
MIRTEC’s industry acclaimed MV-6e OMNI 3D AOI machines are configured with the company’s exclusive OMNI-VISION® 3D inspection system, which combines 15 megapixel CoaXPress camera technology with MIRTEC’s revolutionary digital tri-frequency Moiré 3D system. This proprietary system yields precise height measurement data used to detect lifted component and lifted lead defects as well as 3D solder fillet inspection post reflow. Fully configured, the MV-6 OMNI systems feature four 18 megapixel side-view cameras in addition to the 15 megapixel CoaXPress top-down camera as well as an eight-phase lighting system to provide precision inspection of SMT devices on finished PCB assemblies.
The EM Best of Industry awards program started in 2015 and is organised by India’s leading electronics magazine, Electronics Maker. The award honors leading performers in the industry that drive the industry forward, providing them with a platform to showcase their achievements and product successes. This will help in furthering the growth of the electronics industry, challenging technology to reach the next level.
About MIRTEC
MIRTEC is a leading global supplier of automated optical inspection systems to the electronics manufacturing industry. For further information, visit www.mirtec.com.
